Specifications
100G Transceivers for High-Performance Networks
EN-QSFP28-BXSR is a Four-Channel, Pluggable, LC Duplex, Fiber-Optic QSFP28 Transceiver for 100 Gigabit Ethernet Applications. The transceiver internally multiplexes an XLPPI 4x25G interface into two 50Gb/s electrical channels, transmitting and receiving each optically over one simplex LC fibre using bi-directional optics. It integrates four electrical data lanes in each direction into transmission over a single LC duplex fiber optic cable. Each electrical lane operates at 25.78125 Gbps and conforms to the 100GE XLPPI interface, resulting in an aggregate bandwidth of 100Gbps into a duplex LC cable.
Key Features
- Aggregate bandwidth of > 100Gbps
- Dual-wavelength VCSEL bi-directional optical interface, PAM4 2 × 50-Gb/s 850 nm/900 nm
- Duplex LC receptacle optical interface
- over 70m transmission on OM3 Multimode Fiber (MMF)and 100m on OM4 MMF
- Compliant to the 100GbE XLPPI electrical specification per IEEE 802.3bm
- Compliant to QSFP28 SFF-8636 Specification
- Single +3.3V power supply
- Low power dissipation (Max:3.5W)
- Without digital diagnostic function
- Operating case temperature range:0℃ to 70℃
100G QSFP28 BXSR Optical Transceiver
| Parameter | Specification | Parameter | Specification |
|---|
| Form Factor | QSFP28 | Data Rate | 100Gbps (4 × 25Gbps NRZ) |
| Standard Compliance | IEEE 802.3bm (100GbE XLPPI), QSFP28 SFF-8636 compliant | Modulation | PAM4 (2×50Gb/s per wavelength) |
| Wavelength | 850nm / 900nm (dual-wavelength BiDi) | Connector | Duplex LC |
| Fiber Type | Multimode Fiber (MMF, OM3/OM4) | Max Reach | 70m (OM3), 100m (OM4) |
| Transmit Power | -6 dBm to +4.0 dBm (avg. optical power per channel) | Receiver Sensitivity | ≤ -8 dBm (per channel) |
| Optical Budget | ~1.9 dB | Lane Configuration | 4 Tx / 4 Rx lanes |
| Host Interface | QSFP28 MSA, SFF-8636 | FEC Requirement | RS-FEC (per host platform) |
| Power Supply | 3.3V | Power Consumption | ≤ 3.5W |
| Storage Temperature | -40°C to 85°C | Operating Temperature | 0°C to 70°C (Commercial) |
| Cable Type | Duplex LC multimode cable |
Connectivity examples
Switch-to-switch (leaf-spine)
This figure shows a direct connectivity between two switches using 100GBASE-SR4 QSFP28 transceivers connected by 1x multi-mode MTP to MTP patch cable.
Switch-to-server
