FAQ

Integration Across All Products

Can TAPstack feed PacketMaestro or PM PRO directly?▼

Yes — TAPs provide the raw, unmodified packet stream that PacketMaestro and PM PRO can aggregate and filter.

How does PacketMaestro integrate with PM PRO?▼

PacketMaestro handles high-speed aggregation and preprocessing, while PM PRO performs deep analytics and advanced packet manipulation.

Does MaestroVision manage both PM and PM PRO?▼

Yes — it provides centralized, unified management for all visibility nodes.

Can TAP outputs be load-balanced across PM PRO appliances?▼

Yes — PacketMaestro can aggregate multiple TAP feeds and distribute them across one or more DPUs.

Is the overall system modular?▼

Yes — the architecture is intentionally modular: TAPs → PacketMaestro → PacketMaestro PRO → Monitoring/Security Tools, all centrally managed by MaestroVision.

Ready-to-Plug SONiC Switches

What is a Ready-to-Plug (R2G) SONiC switch?▼

A Ready-to-Plug switch is a fully integrated solution that includes pre-installed Broadcom SONiC OS, validated transceivers/DACs, airflow/PSU configurations, and multi-year support — ready for immediate deployment with no extra integration work.

What's the difference between Broadcom SONiC and Community SONiC?▼

Broadcom SONiC is a commercial distribution with advanced features (like PTP, RoCEv2, Drop Monitor) and formal support. Community SONiC is open-source, community-driven, and ideal for labs or controlled environments. All R2G switches ship with Broadcom SONiC by default.

Do I need to load SONiC myself?▼

No. All R2G switches come preloaded with the Broadcom SONiC distribution. Configuration and versioning are validated before shipping.

What's included in the 3-year support package?▼

Level 1-3 support, firmware/software patches, hardware warranty, and optional upgrade premium 24x7 support. Premium support includes Broadcom escalation.

Can I use my own optics or cables?▼

Yes, but E.C.I. validates and guarantees compatibility only with our pre-certified optics and cables. Using ECIN-coded optics ensures plug-and-play operation across platforms including Cisco, Nokia, and Juniper.

What's the difference between standard and campus SONiC packages?▼

The Campus Package includes additional features such as PoE, LLDP-MED, 802.1X, dynamic ACLs, and enhanced RADIUS integration — ideal for enterprise access deployments.

Do these switches support AI and ML workloads?▼

Yes. 400G and 800G models support Broadcom's AI SONiC package with features like QPN-based ECMP, DLB, PFC, ECN, RoCEv2, and cut-through switching — optimized for RDMA and GPU-to-storage fabrics.

Can I manage these switches through APIs?▼

Absolutely. SONiC supports gNMI, REST, and NETCONF interfaces, and our R2G switches ship with full programmatic API access enabled (based on package tier).

Is there telemetry and flow visibility included?▼

Yes. The Broadcom base package includes BST (Buffer Snapshot Telemetry), and higher-tier packages support Inband Flow Analyzer (IFA 2.0), Tail Stamping, and Drop Monitor.

Can I upgrade to 5-year support or expand coverage?▼

Yes. All R2G switches support 3-year or 5-year packages, and coverage can be tailored to your needs (L3-only, standard 8x5, or 24x7). Campus and AI packages are also available as optional add-ons.

PacketMaestro (PM)

What does PacketMaestro do?▼

It aggregates, filters, and distributes network traffic to monitoring and security tools.

Which hardware platforms are supported?▼

Certified Edgecore and MICAS switches.

What speeds are supported?▼

10G to 400G with flexible breakout options.

How is traffic processed?▼

Using MAPs and Rules for fine-grained traffic steering.

How is PacketMaestro managed?▼

Through a GUI, CLI, and REST API.

PacketMaestro PRO (PM PRO)

What is PM PRO?▼

A DPU-powered advanced visibility platform for multi-terabit analytics.

What advanced features exist?▼

Deduplication, slicing, masking, tunnel filtering, and GTP/VXLAN processing.

What hardware is supported?▼

ADP100/120 (single DPU) and ADP200/220 (dual DPU).

How is PM PRO configured?▼

Using CLI and a full REST API including ACLs, actions, tunnels, flows, and more.

Where is it used?▼

Ideal for carriers, cloud service providers, and high-speed 100G/400G visibility cores.

MaestroVision

What is MaestroVision?▼

A centralized management platform providing a single pane of glass for PacketMaestro and PM PRO.

How many devices can it manage?▼

10 devices (L10 license) or 25 devices and more (L25 license).

Does it support auto-discovery?▼

Yes, it automatically discovers devices and visualizes network topology.

What analytics does it show?▼

Real-time traffic statistics, telemetry, and MAP utilization.

Does it replace the PacketMaestro GUI?▼

Yes — it adds centralized orchestration while local GUIs remain available for single-unit access.

TAPstack

Are TAPs passive?▼

Fiber TAPs are fully passive, secure, and introduce zero network disruption.

Which split ratios exist?▼

50/50, 60/40, 70/30, 80/20, and 90/10.

What speeds are supported?▼

1G to 400G, including 400G ZR/ZR+ coherent optics.

Do TAPs capture all packets?▼

Yes, including errored and malformed frames.

Do copper TAPs support failsafe?▼

Yes — intelligent bypass with Link-Reflect and SafeSwitch features.

XGS-PON | ONT in a Stick

What is the EN-XGSFPP-OMAC-V2?▼

The EN-XGSFPP-OMAC-V2 is an XGS-PON SFP+ ONT that enables 10G fiber connections in a compact transceiver module. It is designed for FTTH, business, and enterprise applications, providing compatibility with various networking devices.

What are the default login credentials?▼

Default IP: 192.168.11.1
Default Firmware Credentials:
- Web GUI:
  - Username: admin
  - Password: QsCg@7249#5281
- Telnet:
  - Username: root
  - Password: QpZm@4246#5753
8311 Firmware Credentials:
- Username: root
- Password: Aa123456

How long does it take for the module to boot up?▼

The EN-XGSFPP-OMAC-V2 takes approximately 75-85 seconds to fully initialize before becoming accessible.

How do I update the firmware?▼

Firmware updates can be applied through the web interface or using Telnet/SSH. The product must retain its default firmware to maintain warranty coverage.

Is the module compatible with all OLTs?▼

While the EN-XGSFPP-OMAC-V2 is designed for broad compatibility, its operation depends on OLT configurations. Some providers may require specific authentication methods such as serial number (SN) cloning or VLAN settings for successful registration.

How do I check if the module is properly connected?▼

Ensure the SFP+ port LED on your switch/router is active.
Use the command: ping 192.168.11.1 -t to confirm network connectivity.
Verify VLAN and authentication settings with your ISP.

Does this module support SN and LOID authentication?▼

Yes, the EN-XGSFPP-OMAC-V2 supports PON serial number (SN) cloning and LOID authentication, which may be required by certain ISPs.

What is the warranty period?▼

The product comes with a 2-year warranty, but modifying the firmware or using custom software voids the warranty.

Can I use this with a residential ISP like Orange Livebox 7, Bell HomeHub, etc.?▼

While residential ISPs are not officially supported, many users have successfully configured the EN-XGSFPP-OMAC-V2 with services like Orange Livebox 7, Bell HomeHub, and others by replicating the correct PON credentials (SN, OMCI settings, VLAN, and authentication methods) required by their ISP.

How do I enable Telnet and SSH?▼

Go to the Service tab in the Web GUI and enable Telnet/SSH, then save the settings.
